Product details

Outdoor high brightness LED screen by ONLY LED. The 7.62mm is the most popular LED panel for outdoor leddisplay.Outdoor displays are widely used for shops, schools, churches,buses,trams,taxi-roof, outdoor advertising, Outdoor sports broadcast etc.It is light-weight and slim, high brightness and high refresh rate.ONLYLED 7.62mm LED panel uses high-precision die-casting aluminium LED panel,with excellent alignment, it brings the best visual effect to people.It is an ideal products for outdoor digital signages,too.

1.Product introduction

. 7.62mm pixel pitch LED display panel.

. LED panel size 304.8*609.6mm (12 x 24 inhces), weight 6.5kgs (14.3lbs) each panel.

. Patent design LED panel, including global patents.

. Suitable for DOOH digital signages.

. LED panel made of aluminium materials, good cooling effect, working temperature -40℃ to 60℃.

. Extruded aluminium mounting frame and die-casting mounting frames are available for customers choices.

. Support front access and back access installation of LED signs.

. LED panels can be installed in both vertical and horizontal orientations.

. ETL listed LED sign modules by intertek Laboratory. FCC approved.

. Good brightness 10,000cd/m2.

. Fanless design, all electronics fully sealed in the LED panel, entire product IP66 rating.

. Common cathode LEDs and dual voltage power supplies.30~40% Energy saving than others.

2.Product feature and application

. High definition LED panels widely used for outdoor commercial advertising screens,DOOH signages.

. Multi- mounting ways, wall-mount,roof-mount, pole-mount,led trailers and double sided mount.

. Fully sealed LED cabinet,without fans, Ingress protection 67.

. Power and data integrated into one cable and one connector increases functional stability.

. Minimal running gears,reduced cables and connector, all parts highly integrated. Ensure our product have high reliability.

. Every LED panel have built-in receiving card and memo, support chromatic and brightness calibrations.

. Support front and back maintenance,Support landscape and portrait installation

.Good heat dissipation, Driving IC stick to aluminium plate,Aluminium LED panel body has really good heat discharging.ensure the entire led panel have uniform temperature thus has uniform brightness,this perfectly solve the color-splotches.

.We provide modular mounting frames for customers choices.Frame made of aluminium and cut by CNC machine, high accuracy ensures seamless splicing.Customer can assemble a led displays with minimal labor and time.

. One uniform size led panel has many pixel pitches for customers choice 3.17mm 3.8mm 6.3mm 7.6mm and 9.5mm.

. Support remote control and monitoring. Push content from cloud server via WIFI internet or 4G.

3.Product parameters
